TOMZN Din Rail Load Isolating Switch Disconnector 4P DC 1500V 40A Small Size Rotating Handle for Photovoltaic Distribution Box

General

FMPV55-NL1/4 is a small-sized 4-pole photovoltaic load switch. It is installed using a rail system, which is more suitable for the usage environment of the distribution box. This device adopts different wiring methods in different voltage environments, and its rated current will also vary. When the voltage is 1500V and the connection method is Type P, the rated current is 20A. Using the Type T wiring method, the rated current is 40A. You can choose different wiring methods according to your needs. It is recommended to use it in combination with a fuse.

Parameters

Product Model: FMPV55-NL1/4
Product Type: DC load isolating switch
Pole Configuration: 4-Pole DC MCB in 2+2 series connection
Rated Current (Type P): 20A
Rated Current (Type T): 40A
Cable Cross Section: 4-16mm²
Terminal Screw Torque: 1.2-1.8 Nm
