Description

YL223

Connector 3IN 3OUT——-30PCS

FOR 28-14(12) A.W.G. / 0.2-2.5(4) mm²

General

YL223 is a 3‑in‑3‑out screw‑clamp connector for joining three input wires to three outputs. It accepts 28‑14 AWG (0.2‑2.5 mm²) and up to 12 AWG (4 mm²) derated, with a flame‑retardant PA66 housing, tin‑plated brass contacts, and CE/RoHS compliance – supplied in a 30‑piece pack for quick, secure junction wiring.

Product parameters
Product Model: YL223
Type: 3-IN 3-OUT connector
Poles: 3
Wire Range (AWG): 28-14 (12)
Wire Range (mm²): 0.2-2.5 (4)
Rated Voltage: 300 V AC
Rated Current: 15 A (2.5 mm²) / 10 A (4 mm²)
Contact Material: Tin‑plated brass
Insulation: PA66, UL94 V‑0
Temp. Range: -40 °C to +105 °C
Termination: Screw‑clamp
Certifications: CE, RoHS
Pack Qty: 30 pcs
