1PCS TOMZN 5(65)A 230V 50Hz Single Phase DIN Rail kWh Watt Hour Energy Meter Step Motor Impulse Register Dispaly Economical Kind

General

The DDS238-2 is a compact single‑phase DIN rail energy meter designed for active energy measurement in two‑wire AC power networks. With a width of only 2 modules (similar to a circuit breaker), it saves space in distribution cabinets. It operates at 230V ±10%, 50Hz, with a basic current of 5A and a maximum current of 65A. The meter features a 5+1 digit analogue display (one decimal), a starting current of 20mA, and a pulse output of 1000imp/kWh. Accuracy is Class 1 (±1%). Ideal for residential and commercial submetering applications.

Product parameters

Product Model: DDS238‑2
Product Type: Single‑phase DIN rail energy meter
Connection Type: Single‑phase two‑wire (L L N)
Rated Voltage: 230V ±10%
Frequency: 50Hz
Basic Current (Ib): 5A
Maximum Current (Imax): 65A
Starting Current: 20mA
Accuracy: ±1% (Class 1)
Display Type: Analogue display, 5+1 digits (one decimal)
Pulse Output: 1000imp/kWh
Installation: DIN rail
Width: 2 modules (approx. 36mm)
Application: Residential and commercial energy monitoring
