Description

Product attributes

AC DC means the products can work with AC and DC current

AC means the products only work with AC current.

Panel mounted

Advanced pre-setting one week before

Digital electronic timer switch with daily and weekly programs

Repeat programs with 16 on/off setting and manual override

NiH battery power reserve when electric supply cut off

Technical Data:

Model	AHC15A, AHC30A
Temp.range: -20??C+50??C	Power Supply: accorind your order
Power consumption 4.5 VA (MAX)	Display: LCD
Switching contact: 1 changeover switch	Programs:16 on/off each day or week
Hysteresis 2 sec/day (25??C)	Mini interval: 1min
Capacity: 16(8) 250V AC	Black-out: 60 days
Timer range: 1min~168hr	Recharge battery: 1.2V 40Ma
Average error: 1s/24h, 25??C	Weight: 0.15kg
